SDLG968

Basic performance
Rated load (tons) 6 tons or more
Rated load (kg) 6000
Operating weight of the whole machine (kg) 19800
Bucket capacity (m³) 3.5 (3.0-5.0)
Maximum-unloading height (mm) 3250
Unloading distance (mm) 1090
Digging force (digging force) (kN) 210
Engine
Engine model WP10G240E342
Rated power (kw/rpm) 178/2100
Maximum torque (N.m) 1100/1500
Displacement (L) 9.726
Cold Cooling mode: water cooling
Working mode: in-line, water cooling, dry cylinder liner, direct injection
Oil capacity: fuel tank (L) 350
Hydraulic oil tank (L) 220
Engine oil (L) 20
Gearbox: gear setting: front four and rear four
Maximum speed (km/h) 38
Steering system: steering angle 38
Working device action time: sum of three items (s) 10.3
Technical parameters: maximum traction (kN) 180
Machine size: machine length (mm) 8680
Machine width (mm) 3200
Machine height (mm) 3470
Minimum ground clearance (mm) 530
Wheelbase (mm) 3400
Track (mm) 2250
