SANY415

Tonnage (tons) 41
Machine operating weight (kg) 41500
Bucket capacity (m³) 1.9/2.2 (rock)
Performance
Slewing speed (rpm) 8.3
Travel speed (km/h) 5.3/3.2
Gradability (%) 70% (35°)
Ground pressure (Kpa) 75.3
Bucket digging force (kN) 247
Arm digging force (kN) 218
Power system
Engine model 6UZ1
Rated power (kw/rpm) 257/2000
Maximum torque (N.m) 1363/1500
Displacement (L) 9.839
Cylinder Number (units) 6
Cooling method Water cooling
Working mode Direct injection, 6-cylinder 4-stroke, turbocharged intercooler, water cooling
Oil capacity
Fuel tank (L) 690
Engine oil change volume (L) 36
Main body dimensions
Total length for transportation (mm) 11700
Total width for transportation (mm) 3360
Total height for transportation (mm) 3740
Total height of cab (mm) 3470
Onboard width (mm) 3265
Track ground length (mm) 4340
Total length of track (mm) 5320
Track shoe width (mm) 600
Track gauge (mm) 2740
Minimum ground clearance (mm) )505
Minimum turning radius of front working device (mm)4750
Maximum height at minimum turning radius (mm)8785
Rear end turning radius (mm)3740
Number of supporting wheels (single side) (pcs)9
Number of chain wheels (single side) (pcs)2
Number of track shoes (single side) (pcs)51
Operating range
Maximum digging radius (mm)10920
Maximum digging depth (mm)7045
Maximum digging height (mm)9980
Maximum unloading height (mm)6960
Maximum vertical digging depth (mm)4710
