SANY215H

Whatsapp:

+8613592496203

E-mail:

info@goodusedbus.com

Inquiry Now Send Message

Tonnage (tons) 22
Machine operating weight (kg) 22800
Bucket capacity (m³) 1.1-1.15
Performance
Slewing speed (rpm) 11.4
Travel speed (km/h) 5.4/3.4
Bucket digging force (kN) 138
Arm digging force (kN) 107
Maximum traction force (kN) 211
Power system
Engine model Isuzu 4HK1
Rated power (kw/rpm) 133/2000
Maximum torque (N.m) 657/1500
Displacement (L) 5.193
Cooling method Water cooling
Working form Vertical, 4-stroke, water-cooled diesel engine
Operating range
Maximum digging radius (mm) 9745
Maximum digging depth (mm) 6450
Maximum digging height (mm) 9470

Related Products

SANY215H

Machine weight 21900kg Bucket capacity 1.1m³ Power 118/2000kW/rpm Total length (during transportation) 9680mm Total width 2980mm Total height (during transportation) 3440mm Upper width 2728mm Total height (top of cab) 3100mm Standard track shoe width 600mm Track gauge 2380mm Minimum ground clearance 470mm Tail turning radius 2870mm Track ground length 3445mm Track length 4250mm Machine weight 21900kg Bucket capacity 1.1m³ Rated power 118/2000kW/rpm Travel speed (high/low) 5.4/3.4km/h Slewing speed 11.6rpm Gradability 70% (35°) Ground pressure 47.4kPa Bucket digging force 138kN Arm digging force 103kN Maximum digging height 9600mm Maximum unloading height 6730mm Maximum digging depth 6600mm Maximum digging radius 3730mm Maximum vertical arm digging depth 10280mm Minimum swing radius 7680mm
