Machine weight 21900kg
Bucket capacity 1.1m³
Power 118/2000kW/rpm
Total length (during transportation) 9680mm
Total width 2980mm
Total height (during transportation) 3440mm
Upper width 2728mm
Total height (top of cab) 3100mm
Standard track shoe width 600mm
Track gauge 2380mm
Minimum ground clearance 470mm
Tail turning radius 2870mm
Track ground length 3445mm
Track length 4250mm
Machine weight 21900kg
Bucket capacity 1.1m³
Rated power 118/2000kW/rpm
Travel speed (high/low) 5.4/3.4km/h
Slewing speed 11.6rpm
Gradability 70% (35°)
Ground pressure 47.4kPa
Bucket digging force 138kN
Arm digging force 103kN
Maximum digging height 9600mm
Maximum unloading height 6730mm
Maximum digging depth 6600mm
Maximum digging radius 3730mm
Maximum vertical arm digging depth 10280mm
Minimum swing radius 7680mm
