SANY205

Tonnage (tons) 20
Machine operating weight (kg) 21500
Bucket capacity (m³) 0.9~1.1 (1.0)
Performance
Slewing speed (rpm) 11
Travel speed (km/h) 5.4/3.3
Gradability (%) 70%/35°
Ground pressure (Kpa) 47.3
Bucket digging force (kN) 138
Arm digging force (kN) 109
Power system
Rated power (kw/rp m)118/2000
Main dimensions
Total length for transport (mm)9680
Total width for transport (mm)2980
Total height for transport (mm)3440
Total height of cab (mm)3075
Onboard width (mm)2875
Track ground length (mm)3360
Total length of track (mm)4160
Track shoe width (mm)600
Track gauge (mm)2380
Minimum ground clearance (mm)440
Minimum turning radius of front working device (mm)3730
Maximum height at minimum turning radius (mm)7680
Rear end turning radius (mm)2900
Operating range
Maximum digging radius (mm)10280
Maximum digging depth (mm)6600
Maximum digging height (mm)9600
Maximum unloading height (mm)6730
