SANY 55

Tonnage (tons) 5
Machine operating weight (kg) 5780
Bucket capacity (m³) 0.1~0.28 (0.21)
Performance
Slewing speed (rpm) 9.6
Travel speed (km/h) 3.73/2.4
Gradability (%) 70% (35°)
Ground pressure (Kpa) 32.75
Bucket digging force (kN) 45
Arm digging force (kN) 33
Power system
Engine model 4JG1
Rated power (kw/rpm) 36/2100
Maximum torque (N.m)175/1800
Displacement (L)3.059
Number of cylinders (pieces)4
Cooling methodWater cooling
Oil capacity
Fuel tank (L)130
Hydraulic oil tank (L)85
Engine oil change amount (L)9.6
Main body dimensions
Total transport length (mm)5925
Total transport width (mm)2005
Total transport height (mm)2595
Total track length (mm)2545
Track shoe width (mm)400
Track gauge (mm)1600
Minimum ground clearance (mm )330
Rear end swing radius (mm) 1640
Number of supporting wheels (single side) (pcs) 5
Number of chain wheels (single side) (pcs) 1
Number of track shoes (single side) (pcs) 40
Operating range
Maximum digging radius (mm) 6090
Maximum digging depth (mm) 3815
Maximum digging height (mm) 5690
Maximum unloading height (mm) 3930
Maximum vertical digging depth (mm) 3070
Bulldozer lifting or pushing depth (mm) 385/380
