SANY 135

Tonnage (tons) 13
Machine operating weight (kg) 13500
Bucket capacity (m³) 0.22-0.7 (0.6)
Performance
Slewing speed (rpm) 12
Travel speed (km/h) 5.5/3.5
Gradability (%) 70% (35°)
Ground pressure (Kpa) 41.7
Bucket digging force (kN) 92.7
Arm digging force (kN) 66.13
Power system
Engine model Isuzu 4JJ1-XDJAG-01-C3
Rated power (kw/rpm) 73/2000
Maximum torque (N.m) 365 /1600
Displacement (L) 2.999
Cooling method Water cooling
Oil capacity
Fuel tank (L) 240
Hydraulic oil tank (L) 150
Engine oil change volume (L) 15
Main body dimensions
Total length for transportation (mm) 7700
Total width for transportation (mm) 2550
Total height for transportation (mm) 2815
Total height of cab (mm) 2740
Onboard width (mm) 2490
Track ground length (mm) 2930
Total length of crawler (mm) 3665
Track shoe width (mm) 500
Track gauge (mm) 1990
Minimum ground clearance (mm )425
Minimum turning radius of front working device (mm) 2500
Rear end turning radius (mm) 2240
Maximum height at minimum turning radius (mm) 6500
Number of chain rollers (single side) (pcs) 1
Number of track shoes (single side) (pcs) 44
Number of supporting rollers (single side) (pcs) 7
Operating range
Maximum digging radius (mm) 8290
Maximum digging depth (mm) 5510
Maximum digging height (mm) 8685
Maximum unloading height (mm) 6180
Maximum vertical digging depth (mm) 4890
