XCMG 245
Tonnage (tons) 24 Machine operating weight (kg) 25500 Bucket capacity (m³) 0.9-1.4 Boom length (mm) 6000 Arm length (mm) 2964 Performance Slewing speed (rpm) 11.2 Travel speed (km/h) 5.3/3.6 Gradability (%) 35 Ground pressure (Kpa) 56.7 Bucket digging force (kN) 185 Arm digging force (kN) 129 Maximum traction force (kN) 199 Power system Engine model QSB7 Rated power (kw/rpm) 150/2 050 Displacement (L) 6.7 Number of cylinders (pieces) 6 Working mode EFI, 4-stroke, turbocharged, air-to-air intercooling Oil capacity Fuel tank (L) 400 Hydraulic oil tank (L) 220 Engine oil change volume (L) 19.5 Main body dimensions Total transport length (mm) 10170 Total transport width (mm) 3190 Total transport height (mm) 3130 Total track length (mm) 4445 Total track width (mm) 3190 Track gauge (mm) 2590 Counterweight ground clearance (mm) 1062 Minimum ground clearance (mm )1062 Minimum turning radius of front working device (mm)3510 Rear end turning radius (mm)2955 Operating range Maximum digging radius (mm)10240 Maximum digging depth (mm)6972 Maximum digging height (mm)10048 Maximum unloading height (mm)7123 Maximum vertical digging depth (mm)5567
