XCMG 75
Tonnage (tons) 7 Machine operating weight (kg) 7460 Bucket capacity (m³) 0.3 Boom length (mm) 3720 Arm length (mm) 1622 Performance Slewing speed (rpm) 10 Travel speed (km/h) 5.4/2.9 Gradability (%) 70 Bucket digging force (kN) 57 Arm digging force (kN) 38 Maximum traction force (kN) 68.3 Power system Engine model V2607-DI-TE3B Rated power (kw/rpm) 42.4/2000 Maximum torque (N.m) 225.8 Displacement (L) 2.615 Hydraulic system Main pump maximum flow (l/min) 160 Working hydraulic circuit (Mpa) 28 Travel hydraulic circuit (Mpa) 27.4 Slewing hydraulic circuit (Mpa )18.6 Oil capacity Fuel tank (L)130 Hydraulic oil tank (L)76 Engine oil change amount (L)10 Main body size Total length for transportation (mm)6150 Total width for transportation (mm)2230 Total height for transportation (mm)2685 Track shoe width (mm)450 Track gauge (mm)1750 Minimum ground clearance (mm)380 Counterweight ground clearance (mm)815 Minimum turning radius of front working device (mm)1818 Rear end turning radius (mm)1800 Operating range Maximum digging radius (mm)6260 Maximum digging depth (mm)4020 Maximum digging height (mm)7085 Maximum unloading height (mm)5160 Maximum vertical digging depth (mm)2920
