SDLG360
Tonnage (tons) 36 Machine operating weight (kg) 37700 Bucket capacity (m³) 1.9 (1.6-2.2) Performance Slewing speed (rpm) 10 Travel speed (km/h) 3.3/4.5 Bucket digging force (kN) 236 Power system Rated power (kw/rpm) 215 Displacement (L) 13 Main dimensions Total transport length (mm) 11080 Total transport width (mm) 3465 Total transport height (mm) 3580 Operating range Maximum digging radius (mm) 10610 Maximum digging depth (mm) 6850 Maximum unloading height (mm) 7090
Learn More
SDLG360
Tonnage (tons) 36 Machine operating weight (kg) 37700 Bucket capacity (m³) 1.9 (1.6-2.2) Performance Slewing speed (rpm) 10 Travel speed (km/h) 3.3/4.5 Bucket digging force (kN) 236 Power system Rated power (kw/rpm) 215 Displacement (L) 13 Main dimensions Total transport length (mm) 11080 Total transport width (mm) 3465 Total transport height (mm) 3580 Operating range Maximum digging radius (mm) 10610 Maximum digging depth (mm) 6850 Maximum unloading height (mm) 7090
Learn More
SDLG360
Tonnage (tons) 36 Machine operating weight (kg) 37700 Bucket capacity (m³) 1.9 (1.6-2.2) Performance Slewing speed (rpm) 10 Travel speed (km/h) 3.3/4.5 Bucket digging force (kN) 236 Power system Rated power (kw/rpm) 215 Displacement (L) 13 Main dimensions Total transport length (mm) 11080 Total transport width (mm) 3465 Total transport height (mm) 3580 Operating range Maximum digging radius (mm) 10610 Maximum digging depth (mm) 6850 Maximum unloading height (mm) 7090
Learn More
SDLG75
Tonnage (tons) 7 Machine operating weight (kg) 7460 Bucket capacity (m³) 0.3 Boom length (mm) 3720 Arm length (mm) 1622 Performance Slewing speed (rpm) 10 Traveling speed (km/h) 5.4/2.9 Gradability (%) 35 Ground pressure (Kpa) 33.5 Bucket digging force (kN) 57 Arm digging force (kN) 38 Maximum traction force (kN) 68.3 Power system Engine model V2607-DI-TE3B Rated power (kw/rpm) 43/2000 Maximum torque (N.m) 225.8 Displacement (L) 2.615 Number of cylinders (pieces) 4 Hydraulic system Pilot oil circuit (MPa) 3.5 Working hydraulic oil circuit (Mpa) 28 Traveling hydraulic circuit (Mpa) 27.4 Slewing hydraulic circuit (Mpa )20.6 Oil capacity Fuel tank (L)130 Hydraulic oil tank (L)76 Engine oil change amount (L)10 Main body size Total length for transportation (mm)6150 Total width for transportation (mm)2230 Total height for transportation (mm)2685 Onboard width (mm)2070 Track ground length (mm)2195 Track shoe width (mm)450 Track gauge (mm)1750 Minimum ground clearance (mm)380 Counterweight ground clearance (mm)815 Operating range Maximum digging radius (mm)6260 Maximum digging depth (mm)4020 Maximum digging height (mm)7085 Maximum unloading height (mm)5160 Maximum vertical digging depth (mm)2920 Bulldozer blade width×height (mm)2200×396
Learn More
SDLG135
Total mass 12700kg Bucket capacity range 0.48～0.6m³ Maximum digging force 79.5kN Slewing speed 10.3r/min Travel speed (low/high) 3.0/5.1km/h Overall dimensions (length×width×height) 7750×2490×2830 mm Maximum digging radius 8330mm Maximum digging depth 5530mm Maximum unloading height 5980mm Engine power 85kW
Learn More
SDLG655
Tonnage (tons) 5 Machine operating weight (kg) 6050 Bucket capacity (m³) 0.2 (0.1-0.3) Performance Slewing speed (rpm) 11.5 Travel speed (km/h) 2.4/4.8 Ground pressure (Kpa) 32 Bucket digging force (kN) 40 Power system Engine model Kubota V2607 Rated power (kw/rpm) 39/2200 Displacement (L) 3.319 Number of cylinders (pcs) 4 Bore × stroke (mm) 98*110 Cooling method Water cooling Hydraulic system Maximum flow of main pump (l/min) 138 Oil capacity Fuel tank (L) 135 Hydraulic oil tank (L) 157 Engine oil replacement volume (L) 12 Main body size Total length of transport (mm) 5970 Total width of transport (mm) 1960 Total height of transport (mm) 2610 Total length of crawler track (mm) 2490 Wide track shoe (mm) 380 Track gauge (mm) 1520 Minimum ground clearance (mm) 375 Rear end turning radius (mm) 1670 Number of chain rollers (single side) (pcs) 1 Number of supporting rollers (single side) (pcs) 5 Operating range Maximum digging radius (mm) 5990 Maximum digging depth (mm) 3846 Maximum digging height (mm) 5870 Maximum unloading height (mm) 4163
Learn More
