SDLG205
Tonnage (tons) 20 Machine operating weight (kg) 21100 Bucket capacity (m³) 0.95 Performance Slewing speed (rpm) 12.1 Travel speed (km/h) 3.5/5.7 Bucket digging force (kN) 147.1 Power system Rated power (kw/rpm) 125 Main dimensions Total transport length (mm) 9720 Total transport width (mm) 2800 Total transport height (mm) 2940 Operating range Maximum digging radius (mm) 9940 Maximum digging depth (mm) 6730 Maximum unloading height (mm) 6650
Learn More
SDLG205
Tonnage (tons) 20 Machine operating weight (kg) 21100 Bucket capacity (m³) 0.95 Performance Slewing speed (rpm) 12.1 Travel speed (km/h) 3.5/5.7 Bucket digging force (kN) 147.1 Power system Rated power (kw/rpm) 125 Main dimensions Total transport length (mm) 9720 Total transport width (mm) 2800 Total transport height (mm) 2940 Operating range Maximum digging radius (mm) 9940 Maximum digging depth (mm) 6730 Maximum unloading height (mm) 6650
Learn More
SDLG75
Tonnage (tons) 7 Machine operating weight (kg) 7460 Bucket capacity (m³) 0.3 Boom length (mm) 3720 Arm length (mm) 1622 Performance Slewing speed (rpm) 10 Traveling speed (km/h) 5.4/2.9 Gradability (%) 35 Ground pressure (Kpa) 33.5 Bucket digging force (kN) 57 Arm digging force (kN) 38 Maximum traction force (kN) 68.3 Power system Engine model V2607-DI-TE3B Rated power (kw/rpm) 43/2000 Maximum torque (N.m) 225.8 Displacement (L) 2.615 Number of cylinders (pieces) 4 Hydraulic system Pilot oil circuit (MPa) 3.5 Working hydraulic oil circuit (Mpa) 28 Traveling hydraulic circuit (Mpa) 27.4 Slewing hydraulic circuit (Mpa )20.6 Oil capacity Fuel tank (L)130 Hydraulic oil tank (L)76 Engine oil change amount (L)10 Main body size Total length for transportation (mm)6150 Total width for transportation (mm)2230 Total height for transportation (mm)2685 Onboard width (mm)2070 Track ground length (mm)2195 Track shoe width (mm)450 Track gauge (mm)1750 Minimum ground clearance (mm)380 Counterweight ground clearance (mm)815 Operating range Maximum digging radius (mm)6260 Maximum digging depth (mm)4020 Maximum digging height (mm)7085 Maximum unloading height (mm)5160 Maximum vertical digging depth (mm)2920 Bulldozer blade width×height (mm)2200×396
Learn More
SDLG250
Tonnage (tons) 25 Machine operating weight (kg) 24400 Bucket capacity (m³) 1.2 (1.0-1.6) Performance Slewing speed (rpm) 0-11.3 Travel speed (km/h) 3.3/5.5 Bucket digging force (kN) 176 Power system Engine model SD70B Rated power (kw/rpm) 138 Main body dimensions Total transport length (mm) 10205 Total transport width (mm) 3190 Total transport height (mm) 3040 Operating range Maximum digging radius (mm) 10260 Maximum digging depth (mm) 6980 Maximum unloading height (mm) 6800
Learn More
SDLG75
Tonnage (tons) 7 Machine operating weight (kg) 7460 Bucket capacity (m³) 0.3 Boom length (mm) 3720 Arm length (mm) 1622 Performance Slewing speed (rpm) 10 Traveling speed (km/h) 5.4/2.9 Gradability (%) 35 Ground pressure (Kpa) 33.5 Bucket digging force (kN) 57 Arm digging force (kN) 38 Maximum traction force (kN) 68.3 Power system Engine model V2607-DI-TE3B Rated power (kw/rpm) 43/2000 Maximum torque (N.m) 225.8 Displacement (L) 2.615 Number of cylinders (pieces) 4 Hydraulic system Pilot oil circuit (MPa) 3.5 Working hydraulic oil circuit (Mpa) 28 Traveling hydraulic circuit (Mpa) 27.4 Slewing hydraulic circuit (Mpa )20.6 Oil capacity Fuel tank (L)130 Hydraulic oil tank (L)76 Engine oil change amount (L)10 Main body size Total length for transportation (mm)6150 Total width for transportation (mm)2230 Total height for transportation (mm)2685 Onboard width (mm)2070 Track ground length (mm)2195 Track shoe width (mm)450 Track gauge (mm)1750 Minimum ground clearance (mm)380 Counterweight ground clearance (mm)815 Operating range Maximum digging radius (mm)6260 Maximum digging depth (mm)4020 Maximum digging height (mm)7085 Maximum unloading height (mm)5160 Maximum vertical digging depth (mm)2920 Bulldozer blade width×height (mm)2200×396
Learn More
SDLG 210
Machine working weight (kg) 21000 Tonnage (tons) 21 Power Traditional power Bucket backhoe Manufacturer Domestic Power Traditional power Performance Travel speed (km/h) 3.2/5.5 Power system Rated power (kw/rpm) 120kw
Learn More
