SANY485
Tonnage (tons) 48 Machine operating weight (kg) 49500 Bucket capacity (m³) 2.2-3.1 Performance Slewing speed (rpm) 8 Travel speed (km/h) 5.4/3.1 Gradability (%) 70 Ground pressure (Kpa) 87.1 Bucket digging force (kN) 287 Arm digging force (kN) 245 Power system Engine model 6WG1X Rated power (kw/rpm) 300/1800 Maximum torque (N.m) 1950/1400 Displacement (L) 15.681 Gas Number of cylinders (pieces) 6 Cooling method Water cooling Oil capacity Fuel tank (L) 680 Hydraulic oil tank (L) 480 Engine oil replacement volume (L) 50 Main body dimensions Total length for transportation (mm) 12095 Total width for transportation (mm) 3360 Total height for transportation (mm) 3790 Total height of cab (mm) 3470 Onboard width (mm) 3290 Track ground length (mm) 4415 Total length of track (mm) 5440 Track shoe width (mm) 600 Track gauge (mm) 2740 Minimum ground clearance (mm) )560 Counterweight ground clearance (mm)1355 Minimum turning radius of front working device (mm)5240 Maximum height at minimum turning radius (mm)9100 Rear end turning radius (mm)3765 Number of supporting wheels (single side) (pcs)9 Number of chain wheels (single side) (pcs)2 Number of track shoes (single side) (pcs)50 Operating range Maximum digging radius (mm)11860 Maximum digging depth (mm)7490 Maximum digging height (mm)10950 Maximum unloading height (mm)7450...
