SANY60
Tonnage (tons) 6 Machine operating weight (kg) 6000 Bucket capacity (m³) 0.10-0.28 (0.23) Performance Slewing speed (rpm) 9.6 Travel speed (km/h) 4.22/2.25 Gradability (%) 70% (35°) Ground pressure (Kpa) 30.7 Bucket digging force (kN) 45 Arm digging force (kN) 33 Power system Engine model V2607 Rated power (kw/rpm) 36/2100 Maximum torque (N. m)206.9/1100~1500 Displacement (L)2.615 Number of cylinders (pieces)4 Cooling method: water cooling Oil capacity Fuel tank (L)130 Hydraulic oil tank (L)85 Engine oil change amount (L)9.6 Main body dimensions Total transport length (mm)5925 Total transport width (mm)2005 Total transport height (mm)2630 Total track length (mm)2700 Track shoe width (mm)400 Track gauge (mm)1600 Minimum ground clearance (mm )370 Rear end swing radius (mm) 1640 Number of supporting wheels (single side) (pcs) 5 Number of chain wheels (single side) (pcs) 1 Number of track shoes (single side) (pcs) 42 Operating range Maximum digging radius (mm) 6090 Maximum digging depth (mm) 3770 Maximum digging height (mm) 5735 Maximum unloading height (mm) 3975 Maximum vertical digging depth (mm) 3025 Bulldozer lifting or pushing depth (mm) 300/405
