SANY 205
Tonnage (tons) 21 Machine operating weight (kg) 21000 Bucket capacity (m³) 1.0 Performance Slewing speed (rpm) 11 Travel speed (km/h) 5.3/3.2 Gradability (%) 70 Ground pressure (Kpa) 47.3 Bucket digging force (kN) 126 Arm digging force (kN) 103 Power system Engine model Mitsubishi Fuso 4M50 Rated power (kw/rpm) 118 Main dimensions Total transport length (mm) 9680 Total transport width (mm) 2800 Total transport height (mm) 3440 Total cab height (mm) 3100 Track ground length (mm) 3360 Total track length (mm) 4160 Track shoe width (mm) 600 Track gauge (mm) 2830 Minimum ground clearance (mm) )470 Counterweight ground clearance (mm)1100 Minimum turning radius of front working device (mm)3730 Maximum height at minimum turning radius (mm)7680 Rear turning radius (mm)2870 Operating range Maximum digging radius (mm)10280 Maximum digging depth (mm)6600 Maximum digging height (mm)9600 Maximum unloading height (mm)6730
Learn More
SANY265
Tonnage (tons) 26 Machine operating weight (kg) 26500 Bucket capacity (m³) 1.3 Performance Slewing speed (rpm) 10.6 Travel speed (km/h) 5.8/3.7 Gradability (%) 70% (35°) Ground pressure (Kpa) 52.5 Bucket digging force (kN) 175 Arm digging force (kN) 120 Power system Engine model Mitsubishi D06FRC Rated power (kw/rpm) 147/2100 Maximum torque (N.m) 750/1 350 Displacement (L) 6.373 Number of cylinders (pieces) 6 Cooling method Water cooling Oil capacity Fuel tank (L) 475 Hydraulic oil tank (L) 277 Engine oil change volume (L) 29 Main body dimensions Total length for transportation (mm) 10290 Total width for transportation (mm) 3190 Total height for transportation (mm) 3255 Track ground length (mm) 3830 Total length of crawler (mm) 4635 Track shoe width (mm) 600 Track gauge (mm) 2590 Minimum ground clearance (mm) )470 Rear end swing radius (mm) 3105 Number of supporting wheels (single side) (pcs) 9 Number of chain wheels (single side) (pcs) 2 Number of track shoes (single side) (pcs) 51 Operating range Maximum digging radius (mm) 10225 Maximum digging depth (mm) 6705 Maximum digging height (mm) 9745 Maximum unloading height (mm) 6715
Learn More
SANY200
Machine weight 21500kg Bucket capacity 1.0m³ Power 118/2000kW/rpm Machine dimensions Total length (when transporting) 9680mm Total width 2800mm Total height (when transporting) 3440mm Standard track shoe width 600mm Wheel width 3360mm Track gauge 2200mm Minimum ground clearance 470mm Tail turning radius 2870mm Track length 4160mm Performance parameters Machine weight 21500kg Bucket capacity 1.0m³ Rated power 118 /2000kW/rpm Travel speed (high/low) 5.4/3.4km/h Slewing speed 11.6rpm Gradability 70% (35°) Ground pressure 47.4kPa Bucket digging force 128kN Arm digging force 102kN Operating range Maximum digging height 9600mm Maximum unloading height 6730mm Maximum digging depth 6600mm Maximum digging radius 10280mm Maximum height at minimum slewing radius 7680mm Minimum slewing radius 3730mm
Learn More
SANY 135
Tonnage (tons) 13 Machine operating weight (kg) 13500 Bucket capacity (m³) 0.22-0.7 (0.6) Performance Slewing speed (rpm) 12 Travel speed (km/h) 5.5/3.5 Gradability (%) 70% (35°) Ground pressure (Kpa) 41.7 Bucket digging force (kN) 92.7 Arm digging force (kN) 66.13 Power system Engine model Isuzu 4JJ1-XDJAG-01-C3 Rated power (kw/rpm) 73/2000 Maximum torque (N.m) 365 /1600 Displacement (L) 2.999 Cooling method Water cooling Oil capacity Fuel tank (L) 240 Hydraulic oil tank (L) 150 Engine oil change volume (L) 15 Main body dimensions Total length for transportation (mm) 7700 Total width for transportation (mm) 2550 Total height for transportation (mm) 2815 Total height of cab (mm) 2740 Onboard width (mm) 2490 Track ground length (mm) 2930 Total length of crawler (mm) 3665 Track shoe width (mm) 500 Track gauge (mm) 1990 Minimum ground clearance (mm )425 Minimum turning radius of front working device (mm) 2500 Rear end turning radius (mm) 2240 Maximum height at minimum turning radius (mm) 6500 Number of chain rollers (single side) (pcs) 1 Number of track shoes (single side) (pcs) 44 Number of supporting rollers (single side) (pcs) 7 Operating range Maximum digging radius (mm) 8290 Maximum digging depth (mm) 5510 Maximum digging height (mm) 8685 Maximum...
Learn More
SANY265
Tonnage (tons) 26 Machine operating weight (kg) 26500 Bucket capacity (m³) 1.3 Performance Slewing speed (rpm) 10.6 Travel speed (km/h) 5.8/3.7 Gradability (%) 70% (35°) Ground pressure (Kpa) 52.5 Bucket digging force (kN) 175 Arm digging force (kN) 120 Power system Engine model Mitsubishi D06FRC Rated power (kw/rpm) 147/2100 Maximum torque (N.m) 750/1 350 Displacement (L) 6.373 Number of cylinders (pieces) 6 Cooling method Water cooling Oil capacity Fuel tank (L) 475 Hydraulic oil tank (L) 277 Engine oil change volume (L) 29 Main body dimensions Total length for transportation (mm) 10290 Total width for transportation (mm) 3190 Total height for transportation (mm) 3255 Track ground length (mm) 3830 Total length of crawler (mm) 4635 Track shoe width (mm) 600 Track gauge (mm) 2590 Minimum ground clearance (mm) )470 Rear end swing radius (mm) 3105 Number of supporting wheels (single side) (pcs) 9 Number of chain wheels (single side) (pcs) 2 Number of track shoes (single side) (pcs) 51 Operating range Maximum digging radius (mm) 10225 Maximum digging depth (mm) 6705 Maximum digging height (mm) 9745 Maximum unloading height (mm) 6715
Learn More
SANY 245
Tonnage (tons) 24 Machine operating weight (kg) 25500 Bucket capacity (m³) 1.3~1.5 (1.5) Performance Slewing speed (rpm) 10.6 Travel speed (km/h) 5.4/3.4 Gradability (%) 70 Ground pressure (Kpa) 53.2 Bucket digging force (kN) 175 Arm digging force (kN) 120 Power system Engine model D06FRC Rated power (kw/rpm) 147/2100 Maximum torque (N.m) 750/1350 Displacement (L) 6.37 3 Number of cylinders (pieces) 6 Cooling method Water cooling Oil capacity Fuel tank (L) 475 Hydraulic oil tank (L) 277 Engine oil replacement volume (L) 29 Main body dimensions Total length for transportation (mm) 10290 Total width for transportation (mm) 3190 Total height for transportation (mm) 3190 Total height of cab (mm) 3255 Onboard width (mm) 3045 Track ground length (mm) 3640 Total length of track (mm) 4445 Track shoe width (mm) 600 Track gauge (mm) 2590 Minimum ground clearance (mm) )470 Minimum turning radius of front working device (mm)3800 Rear end turning radius (mm)3105 Maximum height at minimum turning radius (mm)8016 Number of chain rollers (single side) (pcs)2 Number of track shoes (single side) (pcs)49 Number of supporting rollers (single side) (pcs)9 Operating range Maximum digging radius (mm)10225 Maximum digging depth (mm)6705 Maximum digging height (mm)9745 Maximum unloading height (mm)6715
Learn More
