SANY75
Tonnage (tons) 7 Machine operating weight (kg) 7280 Bucket capacity (m³) 0.12~0.32 Performance Slewing speed (rpm) 11.5 Travel speed (km/h) 4.4/2.4 Gradability (%) 70% (35°) Ground pressure (Kpa) 33 Bucket digging force (kN) 56 Arm digging force (kN) 38 Power system Engine model Isuzu AU-4LE2X Rated power (kw/rpm) 43/2200 Maximum torque (N.m) 200/ 1600 Displacement (L) 2.179 Number of cylinders (pieces) 4 Cooling method Water cooling Oil capacity Fuel tank (L) 150 Hydraulic oil tank (L) 120 Engine oil change volume (L) 9.5 Main body dimensions Total length for transportation (mm) 6120 Total width for transportation (mm) 2220 Total height for transportation (mm) 2720 Track ground length (mm) 2195 Total length of crawler (mm) 2820 Track shoe width (mm) 450 Track gauge (mm) 1750 Minimum ground clearance (mm )380 Rear end turning radius (mm) 1800 Number of sprocket wheels (single side) (pcs) 1 Number of track shoes (single side) (pcs) 39 Number of supporting wheels (single side) (pcs) 5 Operating range Maximum digging radius (mm) 6240 Maximum digging depth (mm) 4020 Maximum digging height (mm) 7060 Maximum unloading height (mm) 5155 Maximum vertical digging depth (mm) 3290 Bulldozer lifting or pushing depth (mm) 350/360
