SANY225
Tonnage (tons) 23 Machine operating weight (kg) 22300 Bucket capacity (m³) 1.1~1.2 (1.2) Performance Slewing speed (rpm) 11 Travel speed (km/h) 5.4/3.3 Gradability (%) 70% (35°) Ground pressure (Kpa) 47.4 Bucket digging force (kN) 138 Arm digging force (kN) 103 Power system Engine model 4M50 Rated power (kw/rpm) 118/2000 Maximum torque (N.m) 580/1600 Displacement (L) 4.9 Oil capacity Fuel tank (L) 340 Hydraulic oil tank (L) 239 Engine oil change amount (L) 2 Coolant (L )30.9 Main dimensions Total length for transport (mm) 9680 Total width for transport (mm) 2980 Total height for transport (mm) 3440 Total height of cab (mm) 3075 Onboard width (mm) 2875 Track ground length (mm) 3640 Total length of track (mm) 4445 Track shoe width (mm) 600 Track gauge (mm) 2380 Counterweight ground clearance (mm) 440 Minimum turning radius of front working device (mm) 3730 Maximum height at minimum turning radius (mm) 7680 Rear end turning radius (mm )2900 Number of supporting wheels (single side) (pcs)8 Number of chain rollers (single side) (pcs)2 Number of track shoes (single side) (pcs)47 Operating range Maximum digging radius (mm)10280 Maximum digging depth (mm)6600 Maximum digging height (mm)9600 Maximum unloading height (mm)6730
