SDLG 225
Tonnage (tons) 22 Machine operating weight (kg) 21700 Bucket capacity (m³) 1.0 (0.8-1.3) Performance Slewing speed (rpm) 0-12.1 Travel speed (km/h) 3.5/5.7 Bucket digging force (kN) 147.1 Power system Rated power (kw/rpm) 123 Main dimensions Total transport length (mm) 9700 Total transport width (mm) 2990 Total transport height (mm) 2940 Operating range Maximum digging radius (mm) 9940 Maximum digging depth (mm) 6730 Maximum unloading height (mm) 6650
Learn More
SANY 245
Tonnage (tons) 24 Machine operating weight (kg) 25500 Bucket capacity (m³) 1.3~1.5 (1.5) Performance Slewing speed (rpm) 10.6 Travel speed (km/h) 5.4/3.4 Gradability (%) 70 Ground pressure (Kpa) 53.2 Bucket digging force (kN) 175 Arm digging force (kN) 120 Power system Engine model D06FRC Rated power (kw/rpm) 147/2100 Maximum torque (N.m) 750/1350 Displacement (L) 6.37 3 Number of cylinders (pieces) 6 Cooling method Water cooling Oil capacity Fuel tank (L) 475 Hydraulic oil tank (L) 277 Engine oil replacement volume (L) 29 Main body dimensions Total length for transportation (mm) 10290 Total width for transportation (mm) 3190 Total height for transportation (mm) 3190 Total height of cab (mm) 3255 Onboard width (mm) 3045 Track ground length (mm) 3640 Total length of track (mm) 4445 Track shoe width (mm) 600 Track gauge (mm) 2590 Minimum ground clearance (mm) )470 Minimum turning radius of front working device (mm)3800 Rear end turning radius (mm)3105 Maximum height at minimum turning radius (mm)8016 Number of chain rollers (single side) (pcs)2 Number of track shoes (single side) (pcs)49 Number of supporting rollers (single side) (pcs)9 Operating range Maximum digging radius (mm)10225 Maximum digging depth (mm)6705 Maximum digging height (mm)9745 Maximum unloading height (mm)6715
Learn More
SANY 205
Tonnage (tons) 21 Machine operating weight (kg) 21000 Bucket capacity (m³) 1.0 Performance Slewing speed (rpm) 11 Travel speed (km/h) 5.3/3.2 Gradability (%) 70 Ground pressure (Kpa) 47.3 Bucket digging force (kN) 126 Arm digging force (kN) 103 Power system Engine model Mitsubishi Fuso 4M50 Rated power (kw/rpm) 118 Main dimensions Total transport length (mm) 9680 Total transport width (mm) 2800 Total transport height (mm) 3440 Total cab height (mm) 3100 Track ground length (mm) 3360 Total track length (mm) 4160 Track shoe width (mm) 600 Track gauge (mm) 2830 Minimum ground clearance (mm) )470 Counterweight ground clearance (mm)1100 Minimum turning radius of front working device (mm)3730 Maximum height at minimum turning radius (mm)7680 Rear turning radius (mm)2870 Operating range Maximum digging radius (mm)10280 Maximum digging depth (mm)6600 Maximum digging height (mm)9600 Maximum unloading height (mm)6730
Learn More
SANY 215
Tonnage (tons) 21 Machine operating weight (kg) 21900 Bucket capacity (m³) 1.1 (0.8~1.2) Performance Slewing speed (rpm) 11 Travel speed (km/h) 5.4/3.3 Gradability (%) 70% (35°) Ground pressure (Kpa) 47.4 Bucket digging force (kN) 138 Arm digging force (kN) 103 Power system Engine model Mitsubishi 4M50 Rated power (kw/rpm) 118/2000 Maximum torque (N.m) 580/1600 Displacement (L) 4.9 Number of cylinders (pieces) 4 Cooling method Water cooling Oil capacity Fuel tank (L) 390 Hydraulic oil tank (L) 239 Engine oil replacement volume (L) 22 Main body dimensions Total length for transportation (mm) 9680 Total width for transportation (mm) 2980 Total height for transportation (mm) 3440 Total height of cab (mm) 3075 Onboard width (mm) 2875 Track ground length (mm) 3445 Total length of crawler (mm) 4250 Track shoe width (mm) 600 Track gauge (mm) 2380 Minimum ground clearance (mm) )440 Minimum turning radius of front working device (mm)3730 Rear end turning radius (mm)2900 Maximum height at minimum turning radius (mm)7680 Number of chain rollers (single side) (pcs)2 Number of track shoes (single side) (pcs)47 Number of supporting rollers (single side) (pcs)8 Operating range Maximum digging radius (mm)10280 Maximum digging depth (mm)6600 Maximum digging height (mm)9600 Maximum unloading height (mm)6730
Learn More
SDLG 360
Tonnage (tons) 36 Machine operating weight (kg) 37700 Bucket capacity (m³) 1.9 (1.6-2.2) Performance Slewing speed (rpm) 10 Travel speed (km/h) 3.3/4.5 Bucket digging force (kN) 236 Power system Rated power (kw/rpm) 215 Displacement (L) 13 Main dimensions Total transport length (mm) 11080 Total transport width (mm) 3465 Total transport height (mm) 3580 Operating range Maximum digging radius (mm) 10610 Maximum digging depth (mm) 6850 Maximum unloading height (mm) 7090
Learn More
SANY 215
Tonnage (tons) 21 Machine operating weight (kg) 21900 Bucket capacity (m³) 1.1 (0.8~1.2) Performance Slewing speed (rpm) 11 Travel speed (km/h) 5.4/3.3 Gradability (%) 70% (35°) Ground pressure (Kpa) 47.4 Bucket digging force (kN) 138 Arm digging force (kN) 103 Power system Engine model Mitsubishi 4M50 Rated power (kw/rpm) 118/2000 Maximum torque (N.m) 580/1600 Displacement (L) 4.9 Number of cylinders (pieces) 4 Cooling method Water cooling Oil capacity Fuel tank (L) 390 Hydraulic oil tank (L) 239 Engine oil replacement volume (L) 22 Main body dimensions Total length for transportation (mm) 9680 Total width for transportation (mm) 2980 Total height for transportation (mm) 3440 Total height of cab (mm) 3075 Onboard width (mm) 2875 Track ground length (mm) 3445 Total length of crawler (mm) 4250 Track shoe width (mm) 600 Track gauge (mm) 2380 Minimum ground clearance (mm) )440 Minimum turning radius of front working device (mm)3730 Rear end turning radius (mm)2900 Maximum height at minimum turning radius (mm)7680 Number of chain rollers (single side) (pcs)2 Number of track shoes (single side) (pcs)47 Number of supporting rollers (single side) (pcs)8 Operating range Maximum digging radius (mm)10280 Maximum digging depth (mm)6600 Maximum digging height (mm)9600 Maximum unloading height (mm)6730
Learn More
