SANY125
Tonnage (tons) 12 Machine operating weight (kg) 12450 Bucket capacity (m³) 0.22-0.7 (0.55) Performance Slewing speed (rpm) 13.06 Travel speed (km/h) 5.5/3.5 Gradability (%) 70 Ground pressure (Kpa) 41.6 Bucket digging force (kN) 90.6 Arm digging force (kN) 57.2 Power system Engine model Isuzu 4JJ1-XDJAG-01-C3 Rated power (kw/rpm) 73/2000 Maximum torque (N.m) 365/1 600 Displacement (L) 2.999 Cooling method Water cooling Oil capacity Fuel tank (L) 240 Hydraulic oil tank (L) 150 Engine oil change volume (L) 15 Main body dimensions Total length for transportation (mm) 7280 Total width for transportation (mm) 2550 Total height for transportation (mm) 2890 Total height of cab (mm) 2740 Onboard width (mm) 2490 Track ground length (mm) 2680 Total length of track (mm) 3360 Track shoe width (mm) 500 Track gauge (mm) 1990 Minimum ground clearance (mm )425 Minimum turning radius of front working device (mm)2880 Maximum height at minimum turning radius (mm)5905 Rear end turning radius (mm)2205 Number of supporting wheels (single side) (pcs)6 Number of chain wheels (single side) (pcs)1 Number of track shoes (single side) (pcs)41 Operating range Maximum digging radius (mm)7735 Maximum digging depth (mm)5190 Maximum digging height (mm)7695 Maximum unloading height (mm)5440 Maximum vertical digging depth (mm)4720
