SANY 215
Tonnage (tons) 21 Machine operating weight (kg) 21900 Bucket capacity (m³) 1.1 (0.8~1.2) Performance Slewing speed (rpm) 11 Travel speed (km/h) 5.4/3.3 Gradability (%) 70% (35°) Ground pressure (Kpa) 47.4 Bucket digging force (kN) 138 Arm digging force (kN) 103 Power system Engine model Mitsubishi 4M50 Rated power (kw/rpm) 118/2000 Maximum torque (N.m) 580/1600 Displacement (L) 4.9 Number of cylinders (pieces) 4 Cooling method Water cooling Oil capacity Fuel tank (L) 390 Hydraulic oil tank (L) 239 Engine oil replacement volume (L) 22 Main body dimensions Total length for transportation (mm) 9680 Total width for transportation (mm) 2980 Total height for transportation (mm) 3440 Total height of cab (mm) 3075 Onboard width (mm) 2875 Track ground length (mm) 3445 Total length of crawler (mm) 4250 Track shoe width (mm) 600 Track gauge (mm) 2380 Minimum ground clearance (mm) )440 Minimum turning radius of front working device (mm)3730 Rear end turning radius (mm)2900 Maximum height at minimum turning radius (mm)7680 Number of chain rollers (single side) (pcs)2 Number of track shoes (single side) (pcs)47 Number of supporting rollers (single side) (pcs)8 Operating range Maximum digging radius (mm)10280 Maximum digging depth (mm)6600 Maximum digging height (mm)9600 Maximum unloading height (mm)6730
Learn More
SANY 245
Tonnage (tons) 24 Machine operating weight (kg) 25500 Bucket capacity (m³) 1.3~1.5 (1.5) Performance Slewing speed (rpm) 10.6 Travel speed (km/h) 5.4/3.4 Gradability (%) 70 Ground pressure (Kpa) 53.2 Bucket digging force (kN) 175 Arm digging force (kN) 120 Power system Engine model D06FRC Rated power (kw/rpm) 147/2100 Maximum torque (N.m) 750/1350 Displacement (L) 6.37 3 Number of cylinders (pieces) 6 Cooling method Water cooling Oil capacity Fuel tank (L) 475 Hydraulic oil tank (L) 277 Engine oil replacement volume (L) 29 Main body dimensions Total length for transportation (mm) 10290 Total width for transportation (mm) 3190 Total height for transportation (mm) 3190 Total height of cab (mm) 3255 Onboard width (mm) 3045 Track ground length (mm) 3640 Total length of track (mm) 4445 Track shoe width (mm) 600 Track gauge (mm) 2590 Minimum ground clearance (mm) )470 Minimum turning radius of front working device (mm)3800 Rear end turning radius (mm)3105 Maximum height at minimum turning radius (mm)8016 Number of chain rollers (single side) (pcs)2 Number of track shoes (single side) (pcs)49 Number of supporting rollers (single side) (pcs)9 Operating range Maximum digging radius (mm)10225 Maximum digging depth (mm)6705 Maximum digging height (mm)9745 Maximum unloading height (mm)6715
Learn More
SANY60
Tonnage (tons) 6 Machine operating weight (kg) 6000 Bucket capacity (m³) 0.10-0.28 (0.23) Performance Slewing speed (rpm) 9.6 Travel speed (km/h) 4.22/2.25 Gradability (%) 70% (35°) Ground pressure (Kpa) 30.7 Bucket digging force (kN) 45 Arm digging force (kN) 33 Power system Engine model V2607 Rated power (kw/rpm) 36/2100 Maximum torque (N. m)206.9/1100~1500 Displacement (L)2.615 Number of cylinders (pieces)4 Cooling method: water cooling Oil capacity Fuel tank (L)130 Hydraulic oil tank (L)85 Engine oil change amount (L)9.6 Main body dimensions Total transport length (mm)5925 Total transport width (mm)2005 Total transport height (mm)2630 Total track length (mm)2700 Track shoe width (mm)400 Track gauge (mm)1600 Minimum ground clearance (mm )370 Rear end swing radius (mm) 1640 Number of supporting wheels (single side) (pcs) 5 Number of chain wheels (single side) (pcs) 1 Number of track shoes (single side) (pcs) 42 Operating range Maximum digging radius (mm) 6090 Maximum digging depth (mm) 3770 Maximum digging height (mm) 5735 Maximum unloading height (mm) 3975 Maximum vertical digging depth (mm) 3025 Bulldozer lifting or pushing depth (mm) 300/405
Learn More
Caterpillar323
Bucket backhoe Tonnage (tons) 23 Machine operating weight (kg) 24500 Bucket capacity (m³) 1.4 Boom length (mm) 5700 Arm length (mm) 2900 Performance Swing speed (rpm) 11.25 Swing torque (Nm) 82k Bucket digging force (kN) 140 Arm digging force (kN) 107 Power system Engine model Cat® C7.1 Rated power (kw/rpm) 151/2000 Displacement (L) 7 Cylinder diameter × stroke (mm) 105 × 135 Emission standard National IV Hydraulic system Main pump maximum flow (l/min) 429 Working hydraulic oil circuit (Mpa) 35 Travel hydraulic circuit (Mpa) 34.3 Swing hydraulic circuit (Mpa) )27.5 Oil capacity Fuel tank (L)345 Hydraulic oil tank (L)115 Hydraulic system (L)234 Engine oil change volume (L)25 Coolant (L)25 Main body dimensions Total length for transportation (mm)9530 Total width for transportation (mm)2980 Total height for transportation (mm)2960 Track shoe width (mm)600 Track gauge (mm)2380 Minimum ground clearance (mm)470 Counterweight ground clearance (mm)1050 Spacing between center of supporting wheels (mm)3650 Rear end turning radius (mm)2830 Operating range Maximum digging radius (mm)9870 Maximum digging depth (mm)6730 Maximum digging height (mm)9450 Maximum unloading height (mm)6480 Maximum vertical digging depth (mm)5620
Learn More
SANY305
Tonnage (tons) 30 Machine operating weight (kg) 31500 Bucket capacity (m³) 1.65~2.0 (1.65) Performance Slewing speed (rpm) 9.0 Travel speed (km/h) 5.4/3.2 Gradability (%) 70% (35°) Ground pressure (Kpa) 62.3 Bucket digging force (kN) 204 Arm digging force (kN) 153 Power system Engine model Isuzu GH-6HK1 Rated power (kw/rpm) 212/2000 Maximum torque (N.m) 1080/1500 Displacement (L) 7.79 Number of cylinders (pieces) 6 Cooling method Water cooling Oil capacity Fuel tank (L) 540 Hydraulic oil tank (L) 380 Engine oil replacement amount (L) 2*4.0 Coolant (L )35 Main dimensions Total length for transport (mm) 10667 Total width for transport (mm) 3190 Total height for transport (mm) 3470 Total height of cab (mm) 3280 Onboard width (mm) 3175 Track ground length (mm) 3916 Total length of crawler (mm) 4840 Track shoe width (mm) 600 Track gauge (mm) 2590 Minimum ground clearance (mm) 550 Minimum turning radius of front working device (mm) 4000 Maximum height at minimum turning radius (mm) 8405 Rear end turning radius (mm )3315 Number of supporting wheels (single side) (pcs)8 Number of chain rollers (single side) (pcs)2 Number of track shoes (single side) (pcs)47 Operating range Maximum digging radius (mm)10870 Maximum digging depth (mm)6815 Maximum digging height (mm)10497 Maximum...
Learn More
SANY 215
Tonnage (tons) 21 Machine operating weight (kg) 21900 Bucket capacity (m³) 1.1 (0.8~1.2) Performance Slewing speed (rpm) 11 Travel speed (km/h) 5.4/3.3 Gradability (%) 70% (35°) Ground pressure (Kpa) 47.4 Bucket digging force (kN) 138 Arm digging force (kN) 103 Power system Engine model Mitsubishi 4M50 Rated power (kw/rpm) 118/2000 Maximum torque (N.m) 580/1600 Displacement (L) 4.9 Number of cylinders (pieces) 4 Cooling method Water cooling Oil capacity Fuel tank (L) 390 Hydraulic oil tank (L) 239 Engine oil replacement volume (L) 22 Main body dimensions Total length for transportation (mm) 9680 Total width for transportation (mm) 2980 Total height for transportation (mm) 3440 Total height of cab (mm) 3075 Onboard width (mm) 2875 Track ground length (mm) 3445 Total length of crawler (mm) 4250 Track shoe width (mm) 600 Track gauge (mm) 2380 Minimum ground clearance (mm) )440 Minimum turning radius of front working device (mm)3730 Rear end turning radius (mm)2900 Maximum height at minimum turning radius (mm)7680 Number of chain rollers (single side) (pcs)2 Number of track shoes (single side) (pcs)47 Number of supporting rollers (single side) (pcs)8 Operating range Maximum digging radius (mm)10280 Maximum digging depth (mm)6600 Maximum digging height (mm)9600 Maximum unloading height (mm)6730
Learn More
