SANY195
Tonnage (tons) 19 Machine operating weight (kg) 20900 Bucket capacity (m³) 0.8~1.1 (0.95) Performance Slewing speed (rpm) 11 Travel speed (km/h) 5.4/3.3 Gradability (%) 70% (35°) Ground pressure (Kpa) 47.3 Bucket digging force (kN) 138 Arm digging force (kN) 103 Power system Engine model 4M50 Rated power (kw/rpm) 118/2000 Maximum torque (N.m) 580/160 0 Displacement (L) 4.9 Oil capacity Fuel tank (L) 340 Hydraulic oil tank (L) 239 Engine oil change volume (L) 22 Main body dimensions Total length for transportation (mm) 9680 Total width for transportation (mm) 2800 Total height for transportation (mm) 3440 Total height of cab (mm) 3075 Onboard width (mm) 2875 Track ground length (mm) 3260 Total length of crawler (mm) 4060 Track shoe width (mm) 600 Track gauge (mm) 2200 Minimum ground clearance (mm )440 Minimum turning radius of front working device (mm)3730 Rear end turning radius (mm)2900 Maximum height at minimum turning radius (mm)7680 Number of track shoes (single side) (pcs)45 Number of supporting wheels (single side) (pcs)7 Operating range Maximum digging radius (mm)10280 Maximum digging depth (mm)6600 Maximum digging height (mm)9600 Maximum unloading height (mm)9600 Maximum vertical digging depth (mm)6255
