Volvo480
Tonnage (tons) 48 Machine operating weight (kg) 47,900-50,500 Bucket capacity (m³) 1.77-3.80 Boom length (mm) 7 Arm length (mm) 4.8 Performance Slewing speed (rpm) 8.8 Travel speed (km/h) 3.1-5.2 Gradability (%) 35 Ground pressure (Kpa) 73.7 (700mm) Bucket digging force (kN) 285/310.6 Arm digging force (kN) 251 Power system Engine model Volvo VOLVO_D13-T4 (A) Rated power (kw/rpm) 245 Displacement (L) 12.8 Number of cylinders (pieces) 6 Cylinder diameter × stroke (mm) 131*158 Cooling method Water cooling Working mode can meet European Stage IIIB emission requirements Hydraulic system Main pump type piston type Travel hydraulic motor type piston type Swing hydraulic motor type piston type Main pump maximum flow (l/min) 2*358 Pilot oil circuit (MPa) 3.9 Working hydraulic oil circuit (Mpa) 32.4/35.3 Travel hydraulic circuit (Mpa) 32.4 Swing hydraulic circuit (Mpa) 25.8 Boom cylinder – number × cylinder diameter × stroke (mm) 2*165*1590 Arm cylinder – number × cylinder diameter × stroke (mm) 1*190*1850 Bucket cylinder – number × cylinder diameter × stroke (mm) 1*165*1330 Oil capacity Fuel tank (L) 685 Hydraulic oil tank (L) 270 Hydraulic system (L) 525 Engine oil replacement amount (L) 42 Coolant (L )60 Main dimensions Total length for transport (mm) 12140 Total width for transport...
